Description:
Suitable for enterprises that need long time continuous processing.
For frozen meat cutting.
Cutting frozen meat into slice, square block, strip, thick slice, dice.
Applicable place:
Big and Medium-sized meat processing enterprises, food factory, central kitchens, catering industry, butcher shop, meat plant etc,
Featrues:
- Cutting precision reaches 0.1mm, and product consistency is good.
- The tailing equally divided functions, which can automatically divide the excess material into each piece.
- A variety of transmission modes, can be fixed length, fixed pieces, separate piles, etc., to facilitate subsequent processing.
- Adopt principle of sliding cutting, the cutting is labor-saving and the cutting surface is flat and smooth.
- The fastest processing is 130 times/min
- The whole machine adopts 304 stainless steel material to meet the safety and hygiene requirements of the food industry.
- Automatic loading, fixing material, cutting and returning materials, no human intervention is required in the whole process.
- The tailings are automatically popped out to save labor;
- You can connect other devices at the end to facilitate the device connect to production lines.
- Overload protection, IO diagnosis, and door switch protection to maximize the protection of personnel and equipment.
Technical Parameters:
Model | CD-280 | CD-455 |
---|---|---|
Power | 4.5kw | 9.12KW |
Voltage | 380V 50HZ / customizable | 380V 50HZ / customizable |
Speed | 35-85 cuts/min | 35-85 cuts/min |
Max material size | 400×280 mm | 430×700 mm |
Max cutting height | 180mm | 190 mm |
Cutting thickness | 0.5-100 mm | 0.5-100 mm |
Frozen meat temp. | -10℃~0 ℃ | -10℃~0 ℃ |
Dimension | 1050x745x1715 mm | 2800x1200x1600 mm |
Weight | 500kg | 750kg |
